112*52mm Outside Dimension D*H Toroidal Transformer for Audio

112*52mm Outside Dimension D*H Toroidal Transformer for Audio

    • 112*52mm Outside Dimension D*H Toroidal Transformer for Audio
    • 112*52mm Outside Dimension D*H Toroidal Transformer for Audio
    • 112*52mm Outside Dimension D*H Toroidal Transformer for Audio
    • 112*52mm Outside Dimension D*H Toroidal Transformer for Audio
    • 112*52mm Outside Dimension D*H Toroidal Transformer for Audio
    • 112*52mm Outside Dimension D*H Toroidal Transformer for Audio
    • 112*52mm Outside Dimension D*H Toroidal Transformer for Audio

    Подробная информация о продукте:

    Place of Origin: CHINA
    Фирменное наименование: IKP
    Сертификация: CE/UL/REACH/ROHS
    Model Number: Toroidal Transformer

    Оплата и доставка Условия:

    Minimum Order Quantity: 1000
    Цена: 3.00-20.00
    Packaging Details: Carton
    Delivery Time: 10-15 days
    Payment Terms: L/C, T/T
    Supply Ability: 100,000/week
    Контакт
    Подробное описание продукта

    Specifications:

    • Power range:0VA to 5000VA

    • Input / Output: Customized

    • Insulation Class: UL class B, F, H, N (optional)

    • Isolation: 4KV (Hi-pot)

    • Easy to change diameter and height of the core

    • Customized specifications are welcome



      Rated Power

             (VA)

     Outside Dimension

            D*H(mm)

       Weight

          (kg)

        Temp. Rise

               (℃)

    		           Approval
    50 80*37 0.71 45     UL/CE/RoHS/CQC
    100 95*45 1.24 51     UL/CE/RoHS/CQC
    200 112*52 2.04 52     UL/CE/RoHS/CQC
    250 118*53 3.36 53     UL/CE/RoHS/CQC
    500 140*65 4.20 55     UL/CE/RoHS/CQC
    1000 170*75 7.20 58     UL/CE/RoHS/CQC
    1500 180*85 9.75 60     UL/CE/RoHS/CQC
    2000 185*105 12.00 62     UL/CE/RoHS/CQC
    3000 200*120 16.60 64     UL/CE/RoHS/CQC
    5000 230*135 24.00 65     UL/CE/RoHS/CQC



    ◆We can design and manufacture customized part with specific requirement


    112*52mm Outside Dimension D*H Toroidal Transformer for Audio◆We can design and manufacture customized part with specific requirement◆We can design and manufacture customized part with specific requirement



    112*52mm Outside Dimension D*H Toroidal Transformer for Audio112*52mm Outside Dimension D*H Toroidal Transformer for Audio112*52mm Outside Dimension D*H Toroidal Transformer for Audio112*52mm Outside Dimension D*H Toroidal Transformer for Audio
