135*42mm Outside Dimension D*H Toroidal Transformer for Lighting

135*42mm Outside Dimension D*H Toroidal Transformer for Lighting

    • 135*42mm Outside Dimension D*H Toroidal Transformer for Lighting
    • 135*42mm Outside Dimension D*H Toroidal Transformer for Lighting
    • 135*42mm Outside Dimension D*H Toroidal Transformer for Lighting
    • 135*42mm Outside Dimension D*H Toroidal Transformer for Lighting
    • 135*42mm Outside Dimension D*H Toroidal Transformer for Lighting
    • 135*42mm Outside Dimension D*H Toroidal Transformer for Lighting
    • 135*42mm Outside Dimension D*H Toroidal Transformer for Lighting

    Подробная информация о продукте:

    Place of Origin: CHINA
    Фирменное наименование: IKP
    Сертификация: CE/UL/REACH/ROHS
    Model Number: Toroidal Transformer

    Оплата и доставка Условия:

    Minimum Order Quantity: 1000
    Цена: 3.00-20.00
    Packaging Details: Carton
    Delivery Time: 10-15 days
    Payment Terms: L/C, T/T
    Supply Ability: 100,000/week
    Контакт
    Подробное описание продукта

    Specifications:

    • Power range:30VA to 1000VA

    • Input / Output: Customized

    • Insulation Class: UL class B, F, H, N (optional)

    • Isolation: 4KV (Hi-pot)

    • Easy to change diameter and height of the core

    • Customized specifications are welcome



    Rated Power

     (VA)

    Outside Dimension

    D*H(mm)

    Weight

    (kg)

    Temp. Rise

    (℃)

    		 Approval
    30 80*32 0.54 30 UL/CE/RoHS/CQC
    50 90*33 0.78 45 UL/CE/RoHS/CQC
    60 100*33 0.94 47 UL/CE/RoHS/CQC
    80 105*34 1.11 50 UL/CE/RoHS/CQC
    100 110*35 1.29 51 UL/CE/RoHS/CQC
    120 115*35 1.48 52 UL/CE/RoHS/CQC
    250 135*42 2.57 53 UL/CE/RoHS/CQC
    300 152*44 3.28 54 UL/CE/RoHS/CQC
    400 153*50 3.87 54 UL/CE/RoHS/CQC
    500 160*55 4.65 55 UL/CE/RoHS/CQC
    600 175*57 5.63 56 UL/CE/RoHS/CQC
    800 191*62 7.05 57 UL/CE/RoHS/CQC
    1000 192*70 8.00 58 UL/CE/RoHS/CQC


    135*42mm Outside Dimension D*H Toroidal Transformer for Lighting◆We can design and manufacture customized part with specific requirement◆We can design and manufacture customized part with specific requirement



    135*42mm Outside Dimension D*H Toroidal Transformer for Lighting135*42mm Outside Dimension D*H Toroidal Transformer for Lighting135*42mm Outside Dimension D*H Toroidal Transformer for Lighting135*42mm Outside Dimension D*H Toroidal Transformer for Lighting
